Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle
Fork
RockShox Recon Silver RL 150mm | 42mm Offset
Rear Shock
RockShox Deluxe Select | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ
Rear Deraileur
Shimano Deore 11spd
Shifter(s)
Shimano Deore 11spd
Crankset
Rocky Mountain Microdrive | 32T |Sram 76mm BCD | 24mm Spindle | Crank Length: XS = 165mm | SM - XL = 170mm
Bottom Bracket
Rocky Mountain Sealed BB92 - Shimano Compatible
Cassette
SunRace CSMS8 EA1 11-51T
Brakes
Tektro HD-M275 | Shimano Pad Compatible | F:Tektro 180mm | R:Tektro 180mm
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m
Seatpost
Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm
Headset
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Rocky Mountain Sealed Boost 15mm
Hub Rear
Novatec D462 Sealed Boost 148mm
Rims
Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape / Valves / Sealant Not Incl
Tires
WTB Trail Boss Comp 29 x 2.4
Weight (Approx lbs)
35.6 LBS|16.1 KGS
